Dual Circular Polarized Horn Antenna 20dBi Typ. Gain, 10.5-14.5GHz Frequency Ran
Features
Frequency Range: 10.5-14.5 GHz
Gain: 20 dBi
VSWR: <1.5 Typ
Polarization: Dual-Circular-polarized
We support customization!
SHARE PRODUCT:
Specifications
Accessories
|
RM-DCPHA105145-20 |
||
|
Parameters |
Typical |
Units |
|
Frequency Range |
10.5-14.5 |
GHz |
|
Gain |
20 Typ. |
dBi |
|
VSWR |
<1.5 Typ. |
|
|
Polarization |
Dual-Circular-polarized |
|
|
AR |
1.5 |
dB |
|
Cross polarization |
>30 |
dB |
|
Port Isolation |
>30 |
dB |
|
Size |
209.8*115.2*109.2 |
mm |
|
Weight |
1.34 |
kg |
